| CARACTERISTIQUES MATERIELLES |
|
| Interface |
8× 10/100/1000 Mbps RJ45 Ports (Ports 1–4 Support 802.3at PoE+ and 802.3af PoE) |
| |
Auto-Negotiation/Auto MDI/MDIX |
| Nombre de ventilateurs |
Fanless |
| Système de verrou physique |
oui |
| Alimentation |
External Power Adapter (Output: 53.5 VDC/ 1.31 A) |
| Consommation |
Max Power Consumption: 77.3 W (110 V/60 Hz) (with 62 W PD connected) |
| |
Standby Power Consumption: 2.8 W (110V/60 Hz) |
| Ports PoE (RJ45) |
Standard: 802.3af/at compliant |
| |
PoE Ports: 4 Ports |
| |
Power Supply: 62 W |
| Dimensions (LxPxH) |
209×126×26 mm |
| Montage |
Desktop / Wall-Mounting |
| Performances |
|
| Capacité de commutation |
16 Gbps |
| Taux de transfert de paquets |
11.90 Mpps |
| Tableau d'adresses MAC |
8k |
| Mémoire tampon des paquets |
4.1 Mbit |
| Trame Géante |
9 KB |
| CARACTERISTIQUES LOGICIELLES |
|
| Fonctions N2 et N2+ |
16 IP Interfaces: Support IPv4/IPv6 Interface |
| |
Static Routing: 32 IPv4/IPv6 Static Routes |
| |
DHCP Server |
| |
DHCP Relay |
| |
DHCP L2 Relay |
| |
Spanning Tree |
| |
Loopback Detection |
| |
Flow Control |
| |
802.1ab LLDP/ LLDP-MED |
| Caractéristiques avancées |
IGMP Snooping |
| |
Rate Limit |
| |
Storm Control |
| |
Port Isolation |
| Prise en charge IPv6 |
oui |
| VLAN |
oui |
| Liste de contrôle d'accès |
|
| Time-Range |
Time Slice |
| |
Week Time-Range |
| |
Absolute Time-Range |
| Combined ACL |
Source MAC(Subnet Mask) |
| |
Destination MAC(Subnet Mask) |
| |
VLAN ID |
| |
EtherType |
| |
Source IP(Subnet Mask) |
| |
Destination IP(Subnet Mask) |
| |
IP Protocol |
| |
TCP/UDP Source Port |
| |
TCP/UDP Destination Port |
| IPv6 ACL |
|
| Rule Operation |
Permit/Deny |
| Binding |
Port Binding |
| |
VLAN Binding |
| Agrégation de lien |
oui |
| Administration |
|
| Administration Centralisée |
Festa App |
| |
Festa Web Portal |
| Accès Cloud |
Free Cloud Access |
| Fonctions d'administration |
Zero-Touch Provisioning (ZTP) |
| |
Self-Organizing Network (SON) |
| |
Auto Topology |
| |
Multi-site Management |
| |
Remote Maintenance |
| |
Batch Firmware Upgrading |
| |
Batch Configuration |
| |
Integrated Troubleshooting Tools |
| |
Monitor Network Status |
| |
Access Condition Logs and Alerts |
| Autres |
|
| Certification |
CE, FCC, RoHS |
| Contenu de l'emballage |
Festa FS308GP |
| |
Power Adapter |
| |
Installation Guide |
| |
Silicone Feet |
| Système requis |
Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux. |
| Environnement |
Operating Temperature: 0–40 ℃ |
| |
Storage Temperature: -40–70 ℃ |
| |
Operating Humidity: 10–90% RH non-condensing |
| |
Storage Humidity: 5–90% RH non-condensing |
